| Image | Series Name | Part Number | Dimensions(mm) | Spec.Sheet | Application note | Manual |
|---|---|---|---|---|---|---|
|
LO2 | Detection Range: Gxxx1)-T1xx2)C-x3)LO2 | Total : 56, Diameter: 20 |
Down |
- |
Down |
|
LO2.1 | GUVx1)-T1x2)GC-x3)LO2.1 |
Down |
- |
Down |
|
|
LOHT | GUVS-T10EC-x1)LOHT |
Down |
- |
Down |
|
|
LO3 | GUVx-T1xGC-LO3 |
Down |
- |
Down |
|
|
LO3 | GUVx-T1xGC-ILO3 |
Down |
- |
Down |
|
|
LO3 | GUVx-T1xGC-LO3-24 |
Down |
- |
Down |
제품 설명
UV wavelength information
-UV-V : 230~395nm (Peak 360nm)
-UV-A : 230~370nm (Peak 360nm)
-UV-B : 220~320nm (Peak 305nm)
-UV-C : 220~280nm (Peak 265nm)
-Visible Blue(VBL) : 300~470nm (Peak 405nm)
-Visible Green(VGR) : 300~510nm (Peak 385nm)
- Features
-
- AlGaInN-based UV sensor
- Optical fiber
- Fiber length : Standard 1m(±10cm), customized length is available
- Applications
-
- UV curing
- UV lamp/LED monitoring
- Specifications
-
- Power supply : DC 6~26 V or DC 9 ~ 26 V
- Ourput: DC voltage(0~5V) or DC current(4~20 mA)
- Operating temp.: ~ 200 C
